Functional Features：

---

Meet the design and usage requirements of GB17945-2010 "Fire Emergency Lighting and Evacuation Indication System" and GB51309-2018 "Design Standard for Fire Emergency Lighting and Evacuation Indication System";
Using high brightness LED beads, low power consumption, high brightness;
Non polarized two-wire wiring, simple wiring, low failure rate.

Technical Parameter：

---

Pattern panel: single-sided (right facing)
Lamp material: die cast aluminum+tempered glass
Working voltage: DC18V~DC36V
Protection level: IP65
Emergency transition time:<5s
Light source type: LED
Surface brightness: 50-300 (cd/㎡)
Main power consumption: Power saving mode: 0.5W Emergency power mode:<1W
Emergency time: 90 minutes
Luminous flux:>50lm
Lamp size: (width x height x thickness mm) 355 * 165 * 73
Installation method: Wall mounted

Usage environment：

---

Operating temperature: 0 ℃~55 ℃
