Functional Features：

---

The fire extinguishing controller adopts a 192×64 dot matrix liquid crystal display - clear, intuitive, and easy to operate;
Three-level programming password protection, suitable for operations by personnel at different management levels;
1024 records of fire alarm events and 1024 records of other events, with real-time recording of system status events for easy querying;
The multi-line linkage control operation area allows for convenient direct control and operation of on-site valve and electrical equipment, featuring 1 channel of sound and light output control; 1 set of pump start control output, operation feedback, and fault feedback; and 5 sets of valve power control outputs, with start output featuring disconnection detection function.
The micro thermal printer achieves real-time event printing function;
A network consisting of up to 63 on-site manual operation panels is formed through the RS485 bus;
A network can be composed of up to 256 input and output modules through loop cards, supporting dual loops;
Multiple fire extinguishing control cabinets can be networked, and a master unit can form a network with up to 31 slave fire extinguishing control cabinets;
Equipped with a UPS (Uninterruptible Power Supply) and a matching battery pack, the system can select the UPS model and battery pack capacity based on the number of devices it supports, meeting the power supply needs of both the local equipment and on-site devices.
Equipped with a hard disk video recorder (with selectable video input options) and a 19-inch LCD monitor.
Equipped with 1 set of 2U 24V/10A linkage power supply.
This automatic control device consists of a fire suppression controller, UPS (Uninterruptible Power Supply), battery pack, hard disk video recorder, and monitor, and complies with the national standard GB25204-2010;

Technical Parameter：

---

Input voltage: AC220V
Output voltage: Uninterrupted AC220V
Device power consumption: 40W
Uninterruptible power supply power: 600W~1600W
Operating environment: Temperature: 0℃～40℃;
Relative humidity: ≤95%, no condensation;
Size and specification: 1066mm×1314mm×?mm;
