Functional Features：

---

This product is used to connect with DHZ7001 and DHZ7002 measuring wires for temperature measurement.
It can be integrated with our electrical fire monitoring equipment to form an electrical fire monitoring and alarm system.
It is suitable for real-time monitoring of the temperature of power supply lines at the low-voltage output side of distribution rooms, or at distribution cabinets, main distribution boxes, primary and secondary distribution boxes, and other locations for protection objects at all levels.
Epoxy resin casting, with good stability.

Technical Parameter：

---

Line length: 1000 ± 20mm
Detection range: 50℃~150℃
Insulation resistance: 500VDC, 7100mu
Material: metal, plastic shell (with cable tie)
26AWG U1133 Teflon wire (black)
Epoxy resin, black
MTG2-2357F202F(B25/100=3568,R25℃=2.058KΩ 1%
Φ4*20 stainless steel non-through-hole shell
CE003408 connector, pink
2.0*5 heat shrinkable sleeve
2.4*13 heat shrinkable sleeve with adhesive
2.0*10 heat shrinkable sleeve
1.5*10 heat shrink tubing
2.0*10 heat shrinkable sleeve
cable tie
