Functional Features：

---

Detect two channels of three voltages and upload them to the monitor or monitoring extension; Loop bus power supply, centrally and uninterruptedly supplied by the system host; Manually encode the address, each sensor has a unique address code; LCD displays electrical parameters such as voltage.

Technical Parameter：

---

Working voltage: DC24V
Working current: ＜ 1mA
Appearance dimensions: 120mm × 95mm × 65mm

Usage environment：

---

Environmental temperature: -10 ℃ to 50 ℃
Relative humidity: ≤ 95% RH (40 ℃± 2 ℃)
