Functional Features：

---

The GK743Z bus control panel is applied to the G7 series fire alarm system. It communicates in real-time with the controller through the CAN communication bus, and through controller programming, the buttons on the panel correspond to the output modules on the controller bus, thereby realizing the monitoring function of the bus control panel on external devices. The point-to-point control operation is convenient. The GK743 bus control panel comes with 64 buttons, which can correspond to 64 sets of external linkage devices. Each button corresponds to one set of device status lights, used for real-time feedback to external devices

Technical Parameter：

---

Working voltage: DC24V
Static working current: ≤ 35mA
Maximum operating current: ≤ 50mA
Dimensions: 482.6mm × 88.1mm (2U)

Usage environment：

---

Environmental temperature: 0 ℃~40 ℃
Relative humidity: ≤ 95% RH (40 ℃± 2 ℃)
