Functional Features：

---

The LW5606 gas discharge indicator light is installed 30cm above the entrance outside the gas fire extinguishing area to remind personnel not to enter the gas fire extinguishing area during the gas discharge phase to avoid injury. It is used with the GK752 gas fire extinguishing controller and the GM718B module, and DC24V is supplied to light the gas discharge indicator light after receiving the gas spraying reply signal.

Technical Parameter：

---

Operating voltage: DC20V~30V

Operating current: 400mA

Flashing frequency: 1.0Hz～2.0Hz

Overall dimensions: 370×150×58(mm)

Usage environment：

---

Ambient temperature: -10℃～+60℃

storage temperature: -20℃～+70℃

Relative humidity: ≤95%RH（no frost）
