Functional Features：

---

Using an open design, there is no need for pre installation. The high service life comes with built-in wiring lines, making it easy to connect. It is compact, flexible, and easy to construct, saving costs.

Technical Parameter：

---

Rated input current: 10A
Rated output voltage: 5 mA
Built in load resistor: 10 Ω
Working frequency: 50Hz~60HZ
Accuracy level: Level 1
Linearity:<3%
Voltage resistance: 3000V/Min
Insulation strength: 500 M2/500 V/Min

material
Core: Ferrite
Shell: Flame retardant PC/PA6

Usage environment：

---

Working temperature: -12 ℃~+75 ℃
