Functional Features：

---

SG-CANFIBER-120-S adopts optical signal transmission, with a maximum communication distance of 40KM and a maximum transmission rate of 1M for CAN signals. We have selected a dedicated fiber optic communication chip and designed lightning protection and anti-static circuits to ensure stable and reliable data communication, as well as good anti electromagnetic interference function. This model not only allows for flexible wiring such as point-to-point, hand-in-hand, ring network, and star network, but also offers the option of single fiber or dual fiber communication. In addition, this CAN to fiber optic converter also has an external dip switch, which can adjust the baud rate freely by dip.

Technical Parameter：

---

Working voltage: DC9~36V
CAN baud rate: 5K~1MHz
CAN baud rate configuration methods: dip switch configuration, software configuration, adaptive mode
Communication speed:<500Kbps
Communication distance: 40KM
Fiber optic usage: point-to-point hand-in-hand loop network star shaped

Usage environment：

---

Temperature: -30 ℃~75 ℃
Humidity: 5-95% (no condensation)
