Functional Features：

---

Suitable for G6 and G7 controllers, with relay function, protocol conversion function, and routing function. Extending the bus communication distance can effectively expand the coverage range of bus communication and improve the transmission distance of communication. It can achieve protocol conversion between G6 series controllers and G7 series controllers. By installing GM741, the system can achieve networking operations for up to 1017 hosts, greatly expanding the scale and capacity of the system. It can be configured by connecting to a PC through a USB interface. By setting the CAN channel type and functional mode through the upper computer software, it is easy to use, instantly effective, and has two electrically isolated CAN channels. There are power and device status displays.

Technical Parameter：

---

Working voltage: DC9V-28V
Static current: ≤ 50mA
Dimensions: 100mm * 70mm * 25mm
Shell protection level: IP30

Usage environment：

---

Environmental temperature: -10 ℃ to 50 ℃
Relative humidity: ≤ 95% RH (40 ℃± 2 ℃)
